Road Sweeper YHD21

Road Sweeper YHD21

Applications :
City road cleaning, Factory daily cleaning, Community,school cleaning, Square cleaning, Residential area cleaning, etc.
send e-mail info@yhroad.com
  • Overview
  • Features
  • Specifications
  • The excellent sweeping performance and extreme manoeuverability make the YHD21 the optimum compact road sweeper for city cleaning. Its unqiue sole bin hopper concept makes it the most versatile footpath and outdoor sweeping machine on the market today.

    For more sweeping and less transit time. The YHD21 compact road sweeper has a choice of flexible disposal concepts that allows the most efficient sweeping option to be determined in line with your work practices. The ergonomically designed operators cabin that is lockable for operator safety, has an excellent 240 degree all round view. It is a sound-proofed low vibration suspended cabin, all controls are in direct view and reach of the operator. Footpath and outdoor sweeping couldn't be any easier than with the YHD21 compact road sweeper. Service-friendly; easy access to all components.








    Road Sweeper YHD21

    Model YHD21
    Engine Model Kubota D1105 Diesel Engine
    Rated Engine Power 18.1kw/2800rpm
    Wheelbase 1200mm
    Kerb Mass 1400kg
    Max Total Mass 1800kg
    Garbage Bin Volume 240L
    Water Tank Volume 150L
    Sweeping Speed 1-10km/h
    Suction Capacity Granularity 45mm@density2.7g /cm3
    Max Sweeping Width 1.8m
    Max Speed 16km/h
    Minimum Turning Radius 2200mm
    Dimension(LxWxH) 3250x1130x2130mm
CASE
  • One Set of Road Sweeper YHQS5050 Kit Exported to Malaysia
  • 2 Sets of Tractor Mounted Road Sweepers Exported to Tanzania
  • One Ride-on Floor Scrubber Exported to Australia
  • 2 Sets of YHD21 Road Sweepers Exported to Lagos,Nigeria
