Road Sweeper YHQS5050A

Road Sweeper YHQS5050A

Applications :
City road cleaning, Factory daily cleaning, Parking lots cleaning, College, school cleaning etc
send e-mail info@yhroad.com
  • Overview
  • Features
  • Specifications
  • Road Sweeper Truck YHQS5050A adopts the way of suction and sweeping combination, wet dust removal, electro-hydraulic control and hydraulic dumping unloading to clean the road.
    Use the vice-engine to drive the fan and other device.

    With the structure of four mid-mounted disk brushes and one rear-mounted suction nozzle, which provide a large sweeping width, high sweeping efficiency and good traffic ability. Also convenient for adjustment and maintenance of sweeper device and nozzle.

    An automatic clutch is set up on the transmission between the vice-engine and the fan, which can ensure the automatic separation of the vice-engine from the fan when the vice-engine startup or shutdown. Also simplified the operation, reduced the impact on vice-engine and improved the reliability and service life of vice-engine.

    The sweeping disk has the protection function and automatic reset function, which can avoid obstacles automatically and return automatically.

    Three positions of disk brush rotation speed (I. E. HIGH, MID and LOW) are provided for various road conditions to ensure the optimal cleaning effect.









    Road Sweeper YHQS5050A

    Vehicle Parameters Model YHQS5050A
    Overall Dimensions 5665x1900x2710mm
    Chassis Model JX1061TG23
    Fuel Type Diesel
    Total Mass 5430 kg
    Maximum Load 3000 kg
    Wheel Tread (front/rear) 1400/1425 mm
    Wheel Base 3360 mm
    Number of Tires 6
    Wheel Specification 7.00R16
    Maximum Running Speed 95 km/h
    Passengers 2
    Sweeping System Parameters Auxiliary Engine Model HFC4DA1
    Rated Power 57 kw
    Rated Speed 3600 r/min
    Fuel Type Diesel
    Emission standards Euro III
    Sweeping Width 3000 mm
    Sweeping Speed 4-25 km/h
    Maximum Cleanable Particle Size 110 mm
    Garbage Bin Capacity 5 m³
    Hydraulic System Independent Hydraulic Operation Control System Using the hydraulic unit to achieve the movement of four sweeping disc rotation, lifting, stretching; and container's lifting
    System Pressure 13Mpa
CASE
  • One Set of Road Sweeper YHQS5050 Kit Exported to Malaysia
  • 2 Sets of Tractor Mounted Road Sweepers Exported to Tanzania
  • One Ride-on Floor Scrubber Exported to Australia
  • 2 Sets of YHD21 Road Sweepers Exported to Lagos,Nigeria
